Detailed Specs

Make

XL SPECIALIZED

Condition

New

Vehicle Category

Semi-Trailers - Lowboy Trailers

Model

XL 110 LOW-PROFILE HDG

Year

2024

Axle

Tri

Composition

Steel

Fixed Axle

Fixed

Length

636.000000000000

Suspension

Air Ride

Width

102

Notes

OVERALL LENGTH: 53′ OVERALL WIDTH:102″ CAPACITY: 110,000 LB DISTRIBUTED; 110,000 LB IN 12′ GOOSENECK NECK STYLE LOW-PROFILE SCRAPER NECK. LENGTH 13′. KINGPIN SETTING:16″ 42″. SWING CLEARANCE:110″ 84″ 5TH WHEEL HEIGHT: 51″ W/ 5 VARIABLE RIDE HEIGHT POSITIONS. HYDRAULICS RUNS OFF WET KIT (5 TO 12 GPM HYD. REQUIREMENTS), W/ ALUMINUM COVER STANDARD. GROTE TRILLIANT WORK LIGHT. MAIN DECK LENGTH 26′. LOADED DECK HEIGHT: 22″ W/ 6″ GROUND CLEARANCE. DECKING: 1 3/8″ APITONG DECKING, RAISED CENTER DECK OPEN STANDARD. CROSSMEMBERS 10″ & 4″ STUBBED JR I-BEAM 12″ ALTERNATING CENTERS. SIDE BEAMS ( 4 ) 16″ FAB I-BEAMS. TOP FLANGE REINFORCEMENT, FRONT RAMP, AND MAIN DECK. D-RINGS ( 7 ) BENT D-RINGS PER SIDE. OUTRIGGERS: REMOVABLE H.D. SWING OUT OUTRIGGERS – 24″ O/C, CENTER SWINGS TOGETHER. PULLOUT FRONT H.D. OUTRIGGER ( 4 ) OAK OUTRIGGER PLANKS, 2″ X 10″. CHAIN DROPS: CHAIN DROPS ON 24″ CENTERS PER SIDE – OUTSIDE BEAMS. ( 2 ) ADDITIONAL CLEARANCE LIGHTS. ADDITIONAL: MANUAL RIDE HEIGHT CONTROL. PREP FOR SINGLE-AXLE BOOSTER. RAISE AND LOWER VALVE. BUCKET WELL AT REAR OF MAIN DECK WITH PLATE ON BOTTOM – 4 FLAT D-RINGS. 31″ FRONT FLIP RAMPS. AIR LIFT ON REAR AXLE. LIQUID-FILLED AIR GAUGE. TOOLBOX IN FRONT OF MAIN DECK WITH 4 FLAT D-RINGS. ( 2 ) PAIR EZ MOUNT FLAG HOLDERS. RUBBER GLAD HAND COVERS. ( 1 ) 4-WAY PLUG AT REAR. AIR-WEIGH DIGITAL SCALE. PREP FOR POWER BOOSTER. PREP FOR HYDRAULIC FLIP ASSIST. WIDE LOAD SIGN TO FIT STANDARD BRACKETS.
